8 Port POE Managed Switch.
Unlimited hardware warranty & replacement.
Datto Networking Switches allow you to deliver affordable, high-performance switching to seamlessly connect devices and users across a network. With built-in support for PoE+, every Datto Networking Switch can power up to 30 watts on all ports, taking advantage of a wide range of available power budgets.
Datto's Cloud managed Switches are designed to work seamlessly with our Wi-Fi access points and cloud management system, enabling Agilitec to monitor all networks and connected devices from a single multi-tenant view.
Ports & Capacity
| 10/100/1000Mb Ports | 8 |
| SFP Slots | N/A |
| PoE Capable Ports | Ports 1-8 output up to 30W |
| PoE Budget | 55W |
| Switching Capacity | 20Gbps |
Features
| Cloud Management | No onsite management appliance required, automatic firmware upgrades |
| Layer 2 Features | 802.10 VLANs Port Trunking/802.3ad Link Aggregation, Port Mirroring, Auto-detect uplink port, QoS (802.1p/CoS,DSCP), Port Isolation IGMP Snooping, Rate Limiting (Tx/Rx), Flow Control, LLDP, MAC ACLS, IPv4 ACLs, Jumbo Frames |
| Spanning Tree Protocol | 802.1D Spanning Tree (STP), 802.1w Rapid Spanning Tree (RSTP), 802.1s Multiple Spanning Tree (MSTP) |
| Quality of Service | 802.1p/CoS, DSCP |
| PoE Management | Power on/off per port, Power class configuration, Power feeding with priority, User defined power limit |
Hardware & Environmental
| Warranty | Lifetime Warranty |
| Mounting | Desktop, Wall Mount |
| Power Supply | External Power Supply |
| Power Cable | US/EU/UK/AUV |
| PoE Standard | IEEE 802.3at/af up to 30W per port |
| SDRAM | 256MB |
| Flash Memory | 32MB |
| LED Indicators | Power, Fault, PoE Max, LAN Mode, PoE Mode, Link/Act |
| Dimensions | 238.8 x 104.1 x 27.9 mm (9.4” x 4.1” x 1.1”) |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Storage Temperature | -20°C to 70°C (-4° to 158°F) |
| Humidity | 5 to 95% non-condensing |
